BILLmanager structure

BILLmanager is a platform with a complex architecture. The platform manages processes related to payment processing and interaction with users. The key components of the platform architecture are:

• web server (ihttpd);
• database;
• BILLmanager (COREmanager and billmgr.so);
• external applications as part of BILLmanager;
• CGI application (accessible through the web server);
• third-party external applications;
• file system.

BILLmanager operating scheme

BILLmanager operating scheme

• Web server — an application that provides interaction with the platform through the web interface. For more details, see the BILLmanager Interface section and the article ihttpd web-server configuration
• DB  — MySQL or MariaDB DBMS. Required to store customer information, payments, settings, and other data necessary for the platform to function. For more details, see Database structure
• BILLmanager — platform for automation. It is based on the COREmanager framework and the billmgr.so library. Also includes:
  • API-functions — provide interfaces for integrating BILLmanager with external systems and applications. For more details, see Guide to ISPsystem software API;
  • plugins;
  • database;
  • files — interface descriptions in XML format, user settings, technical support documents, various images and files for the web interface;
  • modules — e.g. payment modules, service handlers, workflow, etc.
• mgrctl — an application to perform platform operations, including user management, settings, and payment processing. For more details, see Mgrctl utility
• FS — file system. Responsible for storing files and documents related to BILLmanager operation, including reports and document templates
• CGI — Common Gateway Interface. It is used to handle requests related to script execution and server communication
• Input — sources of incoming requests. If the billing process is not running, calling the function through any of these mechanisms will cause it to start:

  • web server (ihttpd);
  • mgrctl;
  • mgr_client::Local — library for executing queries to the platform from C++ code. It is used when writing client plug-ins or modules;

• Output — data output format. Defined by the out query string parameter. For example:

  • html;
  • xml;
  • JSON;
  • text.
